How do I operate a PLJW 109?

How do I operate a PLJW 109? - Proline Range Hoods

The PLJW 109 wall range hood is easy to use. Check out the video below to learn how to operate your PLJW 109.

https://youtu.be/rTQwj6rMgO8


Note: In the video, we have dimmable Halogen lights in the 109. But it comes with LED lights.

PLJW 109 Control Panel

The main control panel is under the front of the range hood. The button on the left with the sun icon turns the lights on and off.

The second button from the left decreases the blower speed, and the third one from the left increases the blower speed.

The 109 has four speeds ranging from 400 CFM to 1000 CFM. 400 CFM is our super-quiet mode which runs at just 2.8 sones. Q stands for quiet, and the speeds increase as you go from left to right.

  • Super-quiet: 400 CFM
  • Low: 600 CFM
  • Medium: 800 CFM
  • High: 1000 CFM

The button on the right side is the power. Press the power button twice to turn the hood on and off.

The PLJW 109 also has an auto-shutoff feature. First, select a fan speed then press the power button within five seconds. You’ll see lights flashing on the control panel. The blower will now shut off in three minutes.

PLJW 109 Inside - Single Blower

The PLJW 109 also has heat lamp sockets in the back of the hood. You can install heat lamps in these sockets, or put LED lights in for additional lighting. To turn the back lights on and off, use the black switch in the front corner of the range hood.

This wall range hood features bright LED lights in the front of the hood to help you see clearly while cooking.

PLJW 109 Wall Range Hood - Front with LED Lights On

We are happy to help you with any questions or concerns you may have. Please create a ticket, email us at support@prolinerangehoods.com or call our support line at (877) 901-5530 to talk to a live representative.
